Air Force photograph by Deirdre Ortiz

Pictured is the inside of the target chamber of the AEDC Range S-1 where hypervelocity impacts take place. S-1 wasn’t active in a decade but is currently undergoing checkout operations in preparation for three upcoming test projects. Several successful test launches have recently been performed in S-1.

Though it hasn’t been active in 10 years, the Range S-1 at the Arnold Engineering Development Complex is currently undergoing checkout operations in preparation for three upcoming test projects.

Lt. Ryan Boudreaux, the Hypervelocity Flyout, Impact and Lethality Ground Test & Evaluation capability manager, and Scott Williams, the capability’s technical lead, are overseeing the checkout of S-1.

“We completed five successful shots in March,” Boudreaux said. “Prior to this effort, the last time any shots were fired in S-1 was in 2007.”

Lt. Col. Jason Armstrong, materiel leader and director of the AEDC Space & Missiles Combined Test Force, noted that reactivating this range is significant for AEDC and its present and future T&E customers.

“The re-activation of S-1 has not only brought back our capability to perform smaller scale hypervelocity impact testing but has also attracted multiple Department of Defense-sponsored customers seeking the type of testing we can now provide in this range,” Armstrong said.

Air Force photograph by Deirdre Ortiz

This is the high pressure section of the AEDC Range S-1 that launches hypervelocity projectiles. It is capable of withstanding forces of up to 400,000 pounds per square inch. Though S-1 hasn’t been active in a decade, it is undergoing checkout operations in preparation for future test projects.

Boudreaux shares Armstrong’s views regarding the importance of this event.

“It’s notable in that these checkout successes will attract new T&E customers to the CTF,” he said.

The focus of the upcoming T&E projects is on research of orbital debris impact. One of the biggest dangers to existing and future space-based assets is hypervelocity impacts from uncontrolled man-made space debris. Range S-1 allows AEDC to show customers what would happen if such a piece of debris impacted one of their space assets.

Range S-1 is 80 feet in length, has a 0.75-inch bore and can launch projectiles between 2 and 8 kilometers per second. It was first used in the late 1980s as a test-bed to try concepts for the larger Range G, AEDC’s 1,000-foot hypervelocity range.


Air Force photograph by Deirdre Ortiz

This metal witness plate was struck by a hypervelocity projectile during a recent checkout of the AEDC Range S-1. S-1 is currently undergoing checkout operations in preparation for three upcoming test projects. Several successful test launches, like the one above, have recently been performed in S-1.
