Northrop Grumman completes first qualification test of new GEM 63XL rocket motor for ULA

0
391
Northrop Grumman conducted the first test of its GEM 63XL rocket motor to serve the United Launch Alliance Vulcan Centaur on Aug. 13, 2020, at its Promontory, Utah, facility. (Northrop Grumman photograph)
Advertisement

Northrop Grumman conducted its first ground test of an extended length 63-inch-diameter Graphite Epoxy Motor (GEM 63XL) Aug. 13, 2020, in Promontory, Utah.

This variation of the company’s GEM 63 strap-on booster was developed in partnership with United Launch Alliance to provide additional lift capability to the Vulcan Centaur vehicle.

“Our new GEM 63XL motors leverage its flight-proven heritage while utilizing state-of-the-art manufacturing technology to enhance launch vehicle heavy-lift capabilities,” said Charlie Precourt, vice president, propulsion systems, Northrop Grumman. “The GEM 63XL increases thrust and performance by 15-20 percent compared to a standard GEM 63.”

The GEM 63XL motor being prepared for static test firing in a Test Area test bay. (Northrop Grumman photograph)

During today’s static test, the motor fired for approximately 90 seconds, producing nearly 449,000 pounds of thrust to qualify the motor’s internal insulation, propellant grain, ballistics and nozzle in a cold-conditioned environment. This test demonstrated materials and technologies similar to the GEM 63 rocket motor that qualified for flight in October 2019.

Northrop Grumman has supplied rocket propulsion to ULA and its heritage companies for a variety of launch vehicles since 1964. The GEM family of strap-on motors was developed starting in the early 1980s with the GEM 40 to support the Delta II launch vehicle. The company then followed with the GEM 46 for the Delta II Heavy, and the GEM 60, which flew 86 motors over 26 Delta IV launches before retiring in 2019 with 100 percent success. The first flight of the GEM 63 motors will be on a ULA Atlas V launch vehicle planned for fourth quarter 2020, and GEM 63XL motors will support the Vulcan rocket in 2021.
